Product Description:
In a typical scrub test, the coating is applied to the Leneta Scrub Test Panel at a specified film thickness, allowed to dry and then subjected to scrubbing with a straight-line scrub tester.
When used in accordance with ASTM D2486, Method A, a 10 mil shim is inserted under the panel to accelerate failure and thereby reduce testing time.
The scrub resistance is the number of scrub cycles required to remove the coating to a specified end point.
Alternatively, the loss in weight is determined after a specified number of scrub resistance cycles, with calculation of equivalent loss in film thickness.
These Scrub Test Panels are ideal for use with the Elcometer 1720 Washability & Abrasion Testers.
Technical Specification:
| Part Number |
Description |
Chart Dimensions |
Quantity
per Box |
Boxes
per Case |
| Box |
Case |
mm |
inches |
| K0004695M068 |
K0004695M268 |
Leneta Scrub Test Panel P121-10N |
165 x 432 |
6½ x 17 |
100 |
5 |
| K0004695M069 |
K0004695M269 |
Leneta Scrub Test Panel P122-10N |
165 x 432 |
6½ x 17 |
100 |
5 |
|
