Product Description:
The Elcometer 266 revolutionises high voltage DC testing of coatings porosity detection making it safer, easier and more reliable than ever before.
The Elcometer 266 revolutionises high voltage DC testing of coatings porosity detection making it safer, easier and more reliable than ever before.
Elcometer 266 Features
 |
- Voltage calculator automatically sets the correct voltage from your coating thickness value
No need to use look up tables. Enter the test standard and the coating thickness and the gauge will automatically programme the correct voltage. |
 |
- Voltage adjustable using the keypad - no need for screwdriver: 0.5kV - 1kV in 50V steps, 1kV to 30kV in 100V steps
Sensitivity to current can be manually preset or automatically adjusted by the gauge for partially conductive coatings. |
 |
- Internal Voltmeter/Jeep tester ensures that the test voltage equals the selected voltage
The closed loop system ensures that the generated test voltage is accurately measured and continuously controlled, regardless of climatic conditions. |
 |
Interchangable probes handles are available, 5kV, 15kV and 30kV DC Versions |
 |
- Audible and visual alarms are activated when a flaw is detected
Bright LEDs on the handle, as well as a loud audible alarm, clearly indicate if the gauge is on (Red) and when a spark is detected (Blue). |
 |
- Battery packs can be recharged inside or outside the gauge for continued use
Batteries are fully charged within 4 hours and provide up to 40 hours continuous use between charges. |
 |
- Adaptor enables use of accessories from other manufacturers
Elcometer 236 & Elcometer 136 Models AP, APS, AP/S1 & AP/S2
Models 780, 785 & 790 Models 10/20 & 14/20 Compact DC & Compact Pulse |
 |
Large, backlit display enables easy viewing even in dark environments. When a flaw is detected the backlight also flashes. |
 |
The optional second hand grip is designed for two handed use without compromising its safety. Ideal for testing pipes and tank floors |
 |
The easy to use menu driven displays can be viewed in multiple languages for optimum versatility. |
Elcometer 266 Safety Features
Technical Specification:
| Part Number |
Description |
| D266----4 |
Elcometer 266* |
| High Voltage Output Accuracy |
±5% or ±50V below 1000 Volts |
| Operating Temperature |
0°C to 50°C (32°F to 120°F) |
| Power Supply |
Rechargeable lithium ion battery, fully charged within 4 hours |
| Measured Current Flow Accuracy |
±5% of full scale Output Current:0 - 100µA maximum |
| Typical Battery Life - Backlight Off (On) |
DC5: 40 (20) hours |
DC15: 20 (15) hours |
DC30: 10 (8) hours |
| Instrument Case Dimensions |
Waterproof, ABS case; 520 x 370 x 125mm (20.5 x 14.5 x 5”) |
| Weight |
Base unit (including battery pack): 1.2kg (2.7lb) Handle: 0.6kg (1.3lb) |
| Certificate available |
Certificate of Calibration: issued for Fixed Calibration equipment and shows readings and traceability |
| Packing List |
Elcometer 266 DC Holiday Detector, lithium battery, curly connection cable for high voltage handle, 10m (32’) signal return lead, battery charger with 3 mains cables (UK, EUR and US), band brush, shoulder strap, tough plastic carry case and operating instructions |
*The Elcometer 266 does not include the probe handle; please select the required handle the accessories
Can be used in accordance with:
ANSI/AWWA C213, AS 3894.1, ASTM C 536, ASTM C 537, ASTM D 4787, ASTM G 6, ASTM D 5162-B, ASTM G 62-B, BS1344-11,
DIN 55670, EN 14430, ISO 2746, JIS K 6766, NACE RP0274, NACE RP0188, NACE RP0190, NACE RP0490, NACE SP0188,
NACE SP0490
Accessories:
|
DC5 (0 - 5KV) |
DC15 (0 - 15kV) |
DC30 (0 - 30kV) |
| Elcometer 266 Probe Handle (Voltage)* |
T26620033-1 |
T26620033-2 |
T26620033-3 |
| Second Hand Grip |
T26620081 |
|
|
| Earth Signal Return Lead |
4m(13'): T99916954 |
10m(32'): T99916996 |
